XR-RD04
Low-Altitude Surveillance Radar
Ku-Band Medium-Range Phased Array Radar
The XR-RD04 Ku-band medium-range phased array radar employs a fully solid-state, fully coherent, pulse-Doppler architecture. Using machine learning for clutter suppression in complex scenes, it achieves all-weather detection and tracking of "Low-Small-Slow" targets with a high target update rate.
Variant Specifications
| Parameter | Value |
|---|---|
| Frequency Band | Ku Band |
| Detection Range | ≥5km (RCS: 0.01m²) |
| Blind Zone | ≤200m |
| Angular Coverage | Azimuth: 0°~360°, Elevation: 0°~30° (configurable) |
| Tracking | Available |
| Velocity Range | 1m/s ~ 100m/s |
| Scan Mode | Azimuth: Mechanical, Elevation: Phase-scan |
| Accuracy | Range: <10m, Azimuth: <0.5°, Elevation: <0.5° |
| Target Update Rate | ≤3.5s |
| Interface | Ethernet |
| Weight | ≤40kg |
| Power Supply | AC220V |
| Power Consumption | ≤500W |
| Dimensions | ≤530mm×590mm×250mm |
| Protection Rating | IP66 |
