CR-RD03 — Ku-Band Long-Range Phased Array Radar
Long-range Ku-band radar for wide-area drone detection and low-altitude perimeter warning, combining mechanical azimuth scan with elevation phase scan for 360-degree coverage.
Because this product has long-range target detection, low-altitude surveillance, and multi-target tracking capabilities, it is subject to China’s dual-use item export control requirements. For products subject to control code 6A108.a (radar equipment), we will complete the required compliance review and any necessary export licensing procedures in accordance with the law before export.
The buyer must cooperate by providing end-user, end-use, non-re-export/non-transfer undertakings, and other necessary documentation. We supply only to lawful, transparent end users that have passed compliance review.
- Ministry of Commerce Announcement 2024 No. 51: Export Control List of Dual-Use Items of the People’s Republic of China
- 2026 Catalogue for the Administration of Import and Export Licenses for Dual-Use Items and Technologies (Ministry of Commerce and General Administration of Customs Announcement 2025 No. 91)
- Reference control code: 6A108.a — radar equipment
The CR-RD03 Ku-band long-range phased array radar employs a fully solid-state, fully coherent, pulse-Doppler architecture. Using machine learning for clutter suppression in complex scenes, it achieves all-weather detection and tracking of "Low-Small-Slow" targets. Azimuth mechanical scan combined with elevation phase scan enables long-range detection of small targets.
Variant Specifications
| Parameter | Value |
|---|---|
| Frequency Band | Ku Band |
| Detection Range | ≥10km (RCS: 0.01m²) |
| Blind Zone | ≤200m |
| Angular Coverage | Azimuth: 0°~360°, Elevation: 0°~30° (configurable) |
| Tracking | Available |
| Velocity Range | 1m/s ~ 100m/s |
| Scan Mode | Azimuth: Mechanical, Elevation: Phase-scan |
| Accuracy | Range: <10m, Azimuth: <0.4°, Elevation: <0.4° |
| Target Update Rate | 6s |
| Interface | Ethernet |
| Weight | ≤50kg |
| Power Supply | AC220V |
| Power Consumption | ≤1200W |
| Dimensions | ≤530mm×650mm×250mm |
| Protection Rating | IP66 |
